Corrosion & Scale Inhibitor for
Steam Boiler & Closed System
Description
& Use
-
Prevents corrosion.
-
Prevents carryover.
-
Suitable for use in boilers over a wide pressure range.
-
Organic
base treatment.
-
Cost-effective concentrate.
Specification
-
Appearance : dark brown liquid.
-
Specific Gravity : 1.12 - 1.18.
-
Solubility in Water : Complete.
-
pH @ 25
oC : 5.2 - 6.8.
(All
values approximate)
Dosage,
Feeding & Control
Mercy Steam 6338
is normally fed to supply corrosion & scale protection for the
steam boiler tubes (Water Side) and using low hardness feed
water.
Mercy Steam 6338
contains a blend of tannin & polymers which will make a filming
layer on the tubes & precipitates hardness salts within the
boiler thus preventing the formation of hard, insulating scale
at heat transfer surfaces.
Mercy Steam 6338
can be
dosed simultaneously with amine on the feed line in a very
concentrated rate (function of make up TDS).
Mercy Steam 6338
is
controlled by a tannin index test on the boiler water. The
specific control ranges vary depending upon system operating
conditions and will be specifies by the technical representative
servicing the facility (required reserve = 120 - 160 ppm).
Packaging
Mercy Steam 6338
is packaged in 30 kg and 240 kg plastic drums.
Safety &
Handling
Mercy Steam 6338
is
non-hazardous, non-flammable but corrosive.
It should
be handled with care.
Ensure that
the operator is fully informed and familiar with the use of the
product.
|
